Text to SQL exploration continues – WrenAI



This write up talks about WrenAI and then compares it to a popular tool Vanna.ai
(Source of all pictures in this blog is WrenAI’s website).

Motivation

In the past few months, we have explored a few text to sql OSS tools out there in the hopes to leverage one in Dalgo and make it available to our NGOs. We reckon this will help the MnE (Monitoring & Evaluation) folks or the analysts in the NGOs, to focus more on the metrics of their program and eliminate time spent in figuring out sql transformations, statements, complex joins etc.

These are some of the write ups we did on this topic of text to sql

• Exploring Vanna ai
• Vanna ai vs Askametric

If you are interested in an understanding Tech4dev’s overall AI strategy – you can check out this Project Tech4Dev’s AI Strategy



WrenAI Architecture

Using RAG (Retrieval Augmented Generation) with LLMs to query databases is a very common practice now, however this method still has its problems/limitations in terms of understanding the context or the business logic around the data. WrenAI tries to tackle these problems

The picture below shows the architecture of WrenAI.



Source – WrenAI

There are 3 components of WrenAI

1. UI – interface to ask questions to your data source
2. AI service – retrieving the context from vector db and prompting the LLM happens here
3. Engine – responsible for connecting to datasource, making sure the SQL executed is in the correct dialect as of the data source, and working out the semantics/metadata of the source.





Setting up WrenAI

They have an installation script that you can easily run and get started (check here). However if you want to have more control over parameters and maybe play around & poke into their open source code you can do the following

• Clone their repo
• Inside the docker directory, create the .env.local file from .env.example
• Add your open ai key in the .env.local. If you want to run a custom llm you will need to copy .env.ai.example to a new .env.ai and add the respective keys there.

Run this docker-compose –env-file .env.local up -d to start all the Wren services. By default it starts at http://localhost:3000



1 . As soon as you open the UI it asks you to set up a data source.

2. It will ask you to select the table(s) that you want to process and query/ask questions on.

3. In the last step, it will ask you to set up relationships between your database tables. It takes the first shot at this automatically by looking at the database’s metadata/schema (primary/foreign keys). You can further add description, business logic to not only the tables but also the relationships. This makes the llm more context aware.



Vanna.ai vs WrenAI

Text to sql comparison

	Vanna.ai	WrenAI
Inner workings	Uses a RAG model	Uses a RAG model + semantic data modelling
LLMs	Multiple llms integration out of the box and can be extended to other llms	Multiple llms integration out of the box and can be extended to other llms
Databases	Supports all standard sql dbs and can be extended to others not present	Supports all standard sql dbs
Github stars	10.6k	1.6k
Feedback loop	Present based on human input	Coming soon
Does it check accuracy of sql query against the db	No, more chances of query being incorrect	Yes, less chances of query being incorrect
OSS apis	Yes	No official documentation yet. It’s coming soon
Threads, can ask follow up questions	No	Yes

Results



For the experiment I am trying to see if I can get accurate results for Dalgo’s operations report that has around 10-15 metrics which we compute weekly. Wren AI claims & guarantees that it only sends metadata and not actual data so there is no risk of PII information being fed to LLMs. For each question, i compare the output from WrenAI and Vanna.ai



Q1. Can you tell how many flow runs failed in the week from 8/17/2024 to 8/24/2024



WrenAI

It gives you the possible interpretation of your question by the system and you can select anyone from it. I selected the third option and it gave me this answer which was very correct and accurate.



Answer

WITH
  failed_flow_runs_data AS
  -- Selects flow_run_ids from the _prefectflowrun table where the state is 'Failed' and the expected start time is within the specified date range.
  (
    SELECT
      "flow_run_id"
    FROM
      "public_ddpui_prefectflowrun" AS "_prefectflowrun"
    WHERE
      "state_name" = 'Failed'
      AND "expected_start_time" >= '2024-08-17'
      AND "expected_start_time" < '2024-08-25'
  )
  -- Counts the number of flow_run_ids from the filtered data to determine the total number of failed flow runs.
SELECT
  COUNT("flow_run_id") AS "failed_flow_runs"
FROM
  "failed_flow_runs_data"



You can ask follow up questions to it and it also has the concept of threads.

WrenAI takes an extra step to improve accuracy of the sql generated.

It validates the sql being generated by the llm by running it. If there is any error, it again sends it back to the llm for modifications. This is done in a continuous loop until it gets to an accurate sql that runs correctly in the source’s database/dialect.



Vanna.ai



Answer

SELECT COUNT(*)
FROM ddpui_prefectflowrun
WHERE state_name = 'failed'
AND start_time >= '2024-08-17'
AND start_time < '2024-08-25';



If you notice, it got the state_name wrong. It should have been Failed instead of failed. Wren AI was successfully able to do that.

I gave the correct query by changing failed to Failed so it has more context for the next question. Vanna ai takes this and generates a new embedding



Q1.1 (Follow up) How many dataflows or pipelines or deployment failed during the week from 8/17/2024 to 8/24/2024  A pipeline is considered to have failed during the week if there is at least one failed flow run during that time period.



WrenAI



Answer

WITH
  failed_deployments_data AS
  -- Selects deployment IDs from the _prefectflowrun table where the state is 'Failed' and the expected start time is within the specified range.
  (
    SELECT
      "deployment_id"
    FROM
      "public_ddpui_prefectflowrun" AS "_prefectflowrun"
    WHERE
      "state_name" = 'Failed'
      AND "expected_start_time" >= '2024-08-17'
      AND "expected_start_time" < '2024-08-25'
  )
  -- Counts the distinct deployment IDs from the filtered data to determine the number of failed deployments.
SELECT
  COUNT(DISTINCT "deployment_id") AS "failed_deployments"
FROM
  "failed_deployments_data"



This answer is a bit off, it’s supposed to join with another pipelines table before counting the failures. I did not update the description in the relationship so I guess it didn’t understand the full context.

I updated the metadata (super easy step from the UI itself) description for the ddpui_prefectflowrun table and also re-phrased the question to see if it could get the join this time.





Vanna.ai

Answer

SELECT COUNT(DISTINCT deployment_id)
FROM ddpui_prefectflowrun
WHERE state_name = 'Failed'
AND start_time >= '2024-08-17'
AND start_time < '2024-08-25';

This is again a bit off but it gave the same answer as WrenAI. An additional join with the dataflows/pipelines table is missing.

I re-trained vanna.ai with some context about the relation between flow run tables and data flow/pipeline tables. This is what i added to its db_description

• The field deployment_id ddpui_prefectflowrun can used to map flow runs to pipelines/dataflows in ddpui_orgdataflowv1

This is the exact same description i added in WrenAI’s model for the deployment_id



Q1.2 (Follow up) Can you give me the name of the dataflow and the count of failed flow runs during the week mentioned above





WrenAI



Answer

-- Counts distinct failed flow runs for each dataflow, ensuring no duplicates are counted.
SELECT
  "_orgdataflow"."name" AS "dataflow_name",
  COUNT(DISTINCT "_prefectflowrun"."flow_run_id") AS "failed_flow_runs"
FROM
  "public_ddpui_prefectflowrun" AS "_prefectflowrun"
  JOIN "public_ddpui_orgdataflowv1" AS "_orgdataflow" ON "_prefectflowrun"."deployment_id" = "_orgdataflow"."deployment_id"
WHERE
  "_prefectflowrun"."state_name" = 'Failed'
  AND "_prefectflowrun"."expected_start_time" >= '2024-08-17'
  AND "_prefectflowrun"."expected_start_time" < '2024-08-25'
GROUP BY
  "_orgdataflow"."name"

It got the query right this time.



Vanna.ai



Answer

SELECT
    deployment_id AS pipeline_name,
    COUNT(*) AS failed_flow_run_count
FROM
    ddpui_prefectflowrun
WHERE
    state_name = 'Failed'
    AND start_time >= '2024-08-17'
    AND start_time < '2024-08-26'
GROUP BY
    deployment_id;

Doesn’t look right, it’s almost the same answer as the previous one. Maybe vanna.ai needs more context but WrenAI does a great due to its Semantic modeling layer in between



Q2. For all connections in the “Dalgo Demo” org, can you tell the average sync duration over the last two months for each one

WrenAI



Answer

WITH
  filtered_org AS
  -- Selects the organization ID and name from the public_ddpui_org table where the organization name matches 'Dalgo Demo'.
  (
    SELECT
      "org"."id" AS "org_id",
      "org"."name" AS "org_name"
    FROM
      "public_ddpui_org" AS "org"
    WHERE
      LOWER("org"."name") = LOWER('Dalgo Demo')
  ),
  filtered_sync_data AS
  -- Joins the filtered organization data with the synchronization statistics to get connection IDs and their corresponding sync durations for the last 60 days.
  (
    SELECT
      "dds"."connection_id" AS "connection_id",
      "dds"."sync_duration_s" AS "sync_duration_s"
    FROM
      "public_ddpui_syncstats" AS "dds"
      JOIN "filtered_org" AS "org" ON "dds"."org_id" = "org"."org_id"
    WHERE
      "dds"."sync_time" >= CURRENT_DATE - INTERVAL '60' DAY
  )
  -- Calculates the average synchronization duration for each connection ID from the filtered synchronization data.
SELECT
  "connection_id",
  AVG("sync_duration_s") AS "average_sync_duration"
FROM
  "filtered_sync_data"
GROUP BY
  "connection_id"

This was correct. If you see it has broken down the question into steps and uses CTE to build the query.

Vanna.ai

Answer

SELECT connection_id, AVG(sync_duration_s) AS average_sync_duration
FROM ddpui_syncstats
WHERE org_id = (SELECT id FROM auth_user WHERE username = 'Dalgo Demo')
  AND sync_time >= NOW() - INTERVAL '2 months'
GROUP BY connection_id;

Vanna couldn’t figure out the join between the ddpui_syncstats and ddpui_org tables.

Q3. Can you give me a pivot table of org names against the roles Each cell represents the count of org users in that role for that particular org



WrenAI

Answer

-- Count of verified org users by role.
SELECT
  "o"."name" AS "org_name",
  "r"."name" AS "role_name",
  COUNT("ou"."id") AS "user_count"
FROM
  "public_ddpui_org" AS "o"
  JOIN "public_ddpui_orguser" AS "ou" ON "o"."id" = "ou"."org_id"
  JOIN "public_ddpui_role" AS "r" ON "ou"."new_role_id" = "r"."id"
WHERE
  "ou"."email_verified" = TRUE
GROUP BY
  "o"."name",
  "r"."name"
ORDER BY
  "o"."name",
  "r"."name"

This is the correct answer. It’s able to multiple joins very easily.



Vanna.ai

Answer

SELECT org_id,
       role,
       COUNT(*) AS user_count
FROM ddpui_orguser
GROUP BY org_id, role
ORDER BY org_id, role;

This is nowhere close to the correct answer. It looks like training Vanna on just an information schema is not enough, it needs a lot more context to output the correct sql. The context can be in the question or in the training documentation.



Conclusion

I think overall WrenAI has performed better but this is just based on a preliminary analysis. We may be able to increase Vanna’s accuracy by coming up with a better training plan.

WrenAI’s semantic modeling layer is a very novel idea and seems to be working nicely. I really like that the UI gives you the entity relationship diagram of your tables where you can easily go & update the business logic or description or context on any table and relation.
